Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    1160 cc
  • Bore:
    3.5 in
  • Stroke:
    2.4 in
  • Compression:
    13.2:1
  • Max Power:
    110.4 kW / 9000 rpm
  • Max Torque:
    95.9 ft-lb / 7000 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer
  • Final Drive:
    Shaft drive
  • Clutch:
    Hydraulic, wet, multi-plate, slip and assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel frame, with forged aluminium outriggers. Fabricated, bolt-on aluminium rear subframe.
  • Swingarm:
    Twin sided "Tri-Link" aluminium swingarm with twin aluminium torque arms.
  • Front Wheel:
    Spoked (Tubeless). 21 x 2.15in.
  • Rear Wheel:
    Spoked (Tubeless). 18 x 4.25in.
  • Front Tyre:
    Metzeler Karoo Street, 90/90-21 (M/C 54V TL)
  • Rear Tyre:
    Metzeler Karoo Street, 150/70R18 (M/C 70V TL)
  • Front Suspension:
    Showa 49mm, semi-active damping USD forks. 220mm travel.
  • Rear Suspension:
    220mm wheel travel Showa semi-active damping monoshock, with automatic electronic preload adjustment and New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up
  • Front Brake:
    Brembo M4.30 Stylema monoblock radial calipers, OC-ABS, twin 320mm floating discs. Magura HC1 span adjustable radial master cylinder with separate reservoir.
  • Rear Brake:
    Brembo single piston caliper, OC-ABS, single 282mm disc. Rear master cylinder with remote reservoir.
  • Instrument Display and Functions:
    Full-colour 7” TFT instrument pack with My Triumph Connectivity System
• Dimensions & Weights

  add remove
  • Width Handlebars:
    33.4 in
  • Height Without Mirror:
    1487 (Low Screen) / 1547 (High Screen) mm
  • Seat Height:
    34.4 in
  • Wheelbase:
    61.4 in
  • Rake:
    23.7 º
  • Trail:
    4.4 in
  • Tank Capacity:
    5.3 gal
  • Wet Weight:
    548.9 lb
• Features

  add remove
  • Lighting:
    All-LED Lighting & Adaptive Cornering Lighting
  • Fuel Tank:
    20 litre aluminium fuel tank
  • Wheels and Tires:
    21" Front / 18" rear lightweight tubeless spoked wheels
  • Clutch:
    Hill Hold
• Technology

  add remove
  • Riding modes:
    6
  • Instruments:
    7 inch TFT instruments with My Triumph Connectivity System
  • ABS:
    ABS and Traction Control
  • Cruise control:
    Yes
  • Shift assist:
    Triumph shift assist (up and down)
