Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    1160 cc
  • Bore:
    3.5 in
  • Stroke:
    2.4 in
  • Compression:
    13.2:1
  • Max Power:
    110.4 kW / 9000 rpm
  • Max Torque:
    95.9 ft-lb / 7000 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer
  • Final Drive:
    Shaft drive
  • Clutch:
    Hydraulic, wet, multi-plate, slip
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    "Tubular steel frame, with forged aluminium outriggers. Fabricated, bolt-on aluminium rear subframe."
  • Swingarm:
    Twin sided "Tri-Link" aluminium swingarm with twin aluminium torque arms.
  • Front Wheel:
    Cast aluminium, 19 x 3.0in
  • Rear Wheel:
    Cast aluminium, 18 x 4.25in
  • Front Tyre:
    Metzeler Tourance, 120/70R19 (M/C 60V TL)
  • Rear Tyre:
    Metzeler Tourance, 150/70R18 (M/C 70V TL)
  • Front Suspension:
    Showa 49mm, semi-active damping USD forks. 200mm travel.
  • Rear Suspension:
    Showa semi-active damping monoshock, with automatic electronic preload adjustment. 200mm wheel travel.
  • Front Brake:
    Brembo M4.30 Stylema monoblock radial calipers, OC-ABS, twin 320mm floating discs. Magura HC1 span adjustable radial master cylinder with separate reservoir.
  • Rear Brake:
    Brembo single piston caliper, OC-ABS, single 282mm disc. Rear master cylinder with remote reservoir.
• Dimensions & Weights

  add remove
  • Width Handlebars:
    33.4 in
  • Height Without Mirror:
    56.5 in
  • Seat Height:
    850/870 mm
  • Wheelbase:
    61.4 in
  • Rake:
    24.0 º
  • Trail:
    4.7 in
  • Tank Capacity:
    7.9 gal
  • Wet Weight:
    255kg (90% fuel - mass in running order) kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    5.1 l/100km / 55,4 mpg (UK)
  • CO₂ Figures:
    119 g/km EURO 5 delaged Regulation (EU) No. 134/2014 Annex VIII
