Specifications

• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    19299
  • MSRP + Destination:
    19299
  • Currency:
    US Dollars
  • Warranty (Months):
    12
  • Warranty (Condition):
    Limited
• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    105
  • Horsepower (kW):
    78.4
  • Cooling:
    Liquid
  • Valve Configuration:
    DOHC
  • Displacement (cc):
    1000
  • Displacement (ci):
    61
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Regular
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Snorkel Air Intake:
    Not Available
  • Engine Block Heater:
    Not Available
  • Other Engine:
    Not Available
• ELECTRIC ENGINE

  add remove
  • Electric Engine:
    Not Available
  • Battery:
    Not Available
  • Battery Charging System:
    Not Available
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Not Available
• DRIVE LINE

  add remove
  • Driveline:
    Standard
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    3
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    No
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Standard
  • Differential Lock Location:
    Front / Rear
  • Other Drive Line:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (mm):
    3370
  • Width (in):
    72
  • Width (mm):
    1830
  • Height (in):
    73
  • Height (mm):
    1850
  • Wheelbase (in):
    102
  • Wheelbase (mm):
    2590
  • Ground Clearance (in):
    14
  • Ground Clearance (mm):
    355.6
  • Weight:
    Standard
  • Wet Weight (lbs):
    1940
  • Wet Weight (kg):
    880
  • Payload Capacity (lbs):
    573
  • Payload Capacity (kgs):
    260
  • GVWR (lbs):
    2868
  • GVWR (kgs):
    1300
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    11.6
  • Fuel Capacity (l):
    43.9
  • Performance:
    Standard
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Chromium Molybdenum
  • Body Material:
    Plastic
  • Exterior Guards:
    Standard
  • Chain Guard:
    No
  • Drive Shaft Guard:
    No
  • Engine Case Guard:
    Yes
  • Exhaust Guard:
    No
  • Light Guard:
    No
  • Front Mud Guards:
    No
  • Rear Mud Guards:
    No
  • Radiator Guard:
    No
  • Exterior Covers:
    Standard
  • CV Boot Cover:
    No
  • Nerf Bars:
    Not Available
  • Front Bumper:
    Standard
  • Front Fender Flairs:
    Standard
  • Rear Fender Flairs:
    Standard
  • Skid Plate:
    Standard
  • A-Arm Skid Plate (Front):
    No
  • A-Arm Skid Plate (Rear):
    No
  • Bash Plate (Front):
    No
  • Bash Plate (Rear):
    No
  • Drive Shaft Skid Plate:
    No
  • Full Length Skid Plate:
    No
  • License Plate:
    Not Available
  • Safety Flag:
    Not Available
  • Cab Canopy:
    Standard
  • Cab Canopy Material:
    Hard
  • Camouflage:
    No
  • Cab Cage:
    Standard
  • Cab Rollbar:
    Standard
  • Cab Doors:
    Standard
  • Cab Door Material:
    Hard
  • Cab / Bed Divider:
    Standard
  • Camouflage Front Body Cover:
    Not Available
  • Other Exterior:
    Not Available
• STEERING

  add remove
  • Steering:
    Standard
  • Steering Control:
    Steering Wheel
  • Steering Type:
    Power
  • Tilt Steering:
    Standard
  • Other Steering:
    Not Available
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Double A-Arm
  • Front Travel (in):
    14
  • Front Travel (mm):
    360
  • Front Stabilizer Bar:
    Yes
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    18
  • Rear Travel (mm):
    457
  • Adjustment Type:
    Shock Mounted Adjustment
  • Number Rear Shock Absorbers:
    2
  • Rear Stabilizer Bar:
    Yes
  • Center Suspension:
    Not Available
  • Other Suspension:
    Not Available
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Front Tire Diameter (in):
    30
  • Rear Tire Diameter (in):
    30
  • Wheel Weights:
    Not Available
  • Tires:
    Standard
  • Tire Brand:
    CST®
  • Tread Type:
    All Terrain
  • Front Tire Width:
    10
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    CST® Stag AT 30 X 10-14
  • Rear Tire (Full Spec):
    CST® Stag AT 30 X 10-14
  • Tire Chains:
    Not Available
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Parking Brake:
    Standard
  • Linked Brake System Front to Rear:
    Not Available
  • Engine Braking:
    Not Available
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Other Brakes:
    Not Available
• TOWING & HAULING

  add remove
  • Front Hitch:
    Not Available
  • Draw Bar:
    Not Available
  • Tow Hook:
    Not Available
  • Trailer:
    Not Available
  • Winch:
    Standard
  • Weight (lbs):
    4500
  • Weight (kgs):
    2041.2
  • Roller Fairlead:
    Standard
  • Other Towing & Hauling:
    Not Available
• STORAGE

  add remove
  • Bed Length (in):
    24
  • Bed Length (mm):
    610
  • Bed Width (in):
    32
  • Bed Width (mm):
    810
  • Bed Height (in):
    12
  • Bed Height (mm):
    300
  • Glove Box / Dash Storage:
    Standard
  • Fender Storage:
    Not Available
  • Front Storage Well:
    Not Available
  • Front Rack:
    Not Available
  • Front Rack Storage:
    Not Available
  • Rear Storage Well:
    Not Available
  • Rear Rack:
    Not Available
  • Rear Rack Storage:
    Not Available
  • Cargo Bed Storage:
    Not Available
  • Rack Rails:
    Not Available
  • Storage Extender:
    Not Available
  • Bag Liners:
    Not Available
  • Cupholder:
    Standard
  • Number Of Cupholders:
    2
  • Storage Cover:
    Not Available
  • Cargo Bed:
    Standard
  • Cargo Bed Material:
    Polyethylene
  • Bed Capacity (lbs.):
    200
  • Bed Capacity (kgs.):
    90
  • Cargo Bed Tilt:
    No
  • Integral Tie-Down Hooks:
    Yes
  • Cargo Bed Cover:
    Not Available
  • Cargo Bed Liner:
    Not Available
  • Map Holder:
    Not Available
  • Helmet Locks:
    Not Available
  • Helmet Storage:
    Not Available
  • Gun Scabbard:
    Not Available
  • Other Storage:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    Bucket
  • Seat Material:
    Vinyl
  • Headrest:
    Yes
  • Seat Specifications:
    Standard
  • Number Of Seats:
    2
  • Number Of Rows:
    1
  • Grab Rail or Strap:
    Standard
  • Heated Seat:
    Not Available
  • Other Seat:
    Not Available
• INSTRUMENTATION

  add remove
  • Digital Instrumentation:
    Standard
  • Clock:
    Standard
  • Speedometer:
    Standard
  • Tachometer:
    Standard
  • Trip Odometer:
    Standard
  • Trip Computer:
    Standard
  • Compass:
    Not Available
  • Hour Meter:
    Standard
  • Lap Timer:
    Not Available
  • Voltage Meter:
    Standard
  • Fuel Level Warning:
    Standard
  • Fuel Level Warning Type:
    Gauge
  • Oil Pressure Gauge:
    Not Available
  • Temperature Warning:
    Standard
  • Temperature Warning Type:
    Gauge
  • Shift Light:
    Not Available
  • Service Reminder:
    Standard
  • Multi-Lingual Instrumentation:
    Not Available
  • Battery Status Gauge:
    Not Available
  • Energy Consumption Gauge:
    Not Available
  • Other Instrumentation:
    Not Available
• LIGHTS

  add remove
  • Headlight(s):
    Standard
  • Type:
    Halogen
  • Halogen Headlight(s):
    Standard
  • Adjustable Headlights:
    Not Available
  • Fog Lights:
    Not Available
  • Headlight Mounts:
    Standard
  • Headlight Mounting Bar:
    Not Available
  • Tail Light / Brake Light:
    Standard
  • Beacon Light:
    Not Available
  • Work Light Front or Rear:
    Not Available
  • Other Lights:
    Not Available
• ELECTRICAL

  add remove
  • Generator:
    Not Available
• GLASS

  add remove
  • Rearview Mirrors:
    Not Available
  • Windshield:
    Not Available
  • Windshield Wipers:
    Not Available
  • Windshield Washer Motor:
    Not Available
  • Other Glass:
    Not Available
• CONVENIENCE

  add remove
  • Engine Immobilizer:
    Not Available
  • Keyless Ignition:
    Not Available
  • Power Outlet:
    Standard
  • Cruise Control:
    Not Available
  • Adjustable Levers:
    Not Available
  • Alarm System:
    Not Available
  • Handlebar Lock:
    Not Available
  • First Aid Kit:
    Not Available
  • Heater:
    Not Available
  • Seat Belts:
    Standard
  • Reverse Alarm:
    Not Available
  • Floor Mats:
    Not Available
  • Other Convenience:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Not Available
  • Speakers:
    Not Available
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Wireless / Connectivity:
    Standard
  • Mobile App Instrumentation:
    Yes
  • Other Audio & Communication:
    Not Available
• YARD EQUIPMENT

  add remove
  • Plow:
    Not Available
  • Plow Actuator:
    Not Available
  • Lawn Mower:
    Not Available
  • Other Yard Equipment:
    Not Available
• MOUNTS

  add remove
  • Gun Scabbard Mount:
    Not Available
  • Plow Mount:
    Not Available
  • Tool Bag Mount:
    Not Available
  • Windshield Mounts:
    Not Available
  • Winch Mount:
    Standard
• PAINT & FINISH

  add remove
  • Paint:
    Standard
  • Decal Kit:
    Standard
  • Other Paint & Finish:
    Not Available
• SPECIAL PACKAGE

  add remove
  • Special Package:
    Not Available
