Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Single Cylinder 4-Stroke SOHC
  • Capacity:
    449.5 cc cc
  • Bore:
    3.7 in
  • Stroke:
    2.5 in
  • Compression:
    13.1:1
  • System:
    Dellorto Throttle Body, Athena EMS
  • Exhaust:
    Single Silencer
  • Final Drive:
    Chain, 13/48
  • Clutch:
    Steel Wet Multi-Plate Belleville Spring, Hydraulic Actuation
  • Gearbox:
    5 Speed
• Chassis

  add remove
  • Frame:
    Aluminium, Spine
  • Swingarm:
    Aluminium Fabrication
  • Front Wheel:
    21" x 1.6"
  • Rear Wheel:
    19" x 2.15"
  • Front Tyre:
    80/100 - 21
  • Rear Tyre:
    110/90 - 19
  • Front Suspension:
    KYB 48mm Coil Spring Fork, Compression/Rebound Adjustment, 310mm Travel
  • Rear Suspension:
    KYB Coil, Compression Adjustment (H and L Speed), Rebound Adjustment, 305mm Travel
  • Front Brake:
    Brembo Twin 24mm Piston, 260mm Disc
  • Rear Brake:
    Brembo Single 26mm Piston, 220mm Disc
  • Instrument Display and Functions:
    Hour Meter, Multifunction Switch Cubes
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.9 in
  • Height Without Mirror:
    50.0 in
  • Seat Height:
    37.8 in
  • Wheelbase:
    58.7 in
  • Rake:
    27.4 º
  • Trail:
    4.6 in
  • Tank Capacity:
    1.8 gal
  • Wet Weight:
    239.42 lbs
