Specifications

• ENGINE

  add remove
  • Engine Type:
    In-Line
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.15
  • Stroke (in):
    2.7
  • Displacement (cc):
    689
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    50
  • Torque RPM:
    6500
  • US Miles Per Gallon (Hwy):
    58
  • Displacement:
    689cc
  • Bore x Stroke:
    80 x 68.6 mm
  • Compression ratio:
    11.5:1
  • Maximum Torque:
    6.9 kg-m (50 ft-lbs.) @ 6,500 rpm
  • Fuel Delivery:
    Mikuni 38 mm dual bore throttle body F.I.
  • Transmission:
    6-speed
  • Final Drive:
    "O"-ring chain
  • Ignition:
    TCI / Electric
  • Lubrication:
    Wet sump
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    82.1
  • Width (in):
    30.7
  • Height (in):
    43.5
  • Wheelbase (in):
    55.1
  • Ground Clearance (in):
    5.5
  • Fuel Capacity (gal):
    3.7
  • Engine Displacement to Weight (cc):
    1.7
  • Wet Weight (lbs):
    406
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.1
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Tire Brand:
    Michelin®
  • Front Tire (Full Spec):
    Michelin Road 5 120/70 ZR17
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.6
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    31.7
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Optional
  • Grab Rail or Strap:
    Standard
