Specifications

• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    6
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    160
  • Horsepower (kW):
    118
  • Horsepower RPM:
    7750
  • Torque (Ft Lbs):
    129
  • Torque (Nm):
    175
  • Torque RPM:
    5250
  • Cooling:
    Liquid / Oil
  • Valves:
    24
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (mm):
    72
  • Bore (in):
    2.83
  • Stroke (mm):
    67.5
  • Stroke (in):
    2.66
  • Displacement (cc):
    1649
  • Displacement (ci):
    100.6
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Premium
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • US Miles Per Gallon (Hwy):
    52
  • Fuel Injector Size (mm):
    52
  • Compression ratio:
    12.2:1
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Gear Ratio (1):
    2.23
  • Gear Ratio (2):
    1.64
  • Gear Ratio (3):
    1.32
  • Gear Ratio (4):
    1.1
  • Gear Ratio (5):
    0.93
  • Gear Ratio (6):
    0.79
  • Reverse:
    No
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    97.9
  • Length (mm):
    2486.7
  • Width (in):
    39.4
  • Width (mm):
    1000
  • Wheelbase (in):
    66.1
  • Wheelbase (mm):
    1680
  • Weight:
    Standard
  • Dry Weight (lbs):
    708
  • Dry Weight (kg):
    321
  • Wet Weight (lbs):
    768
  • Wet Weight (kg):
    348
  • GVWR (lbs):
    1234
  • GVWR (kgs):
    560
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    7
  • Fuel Capacity (l):
    26.5
  • Fuel Capacity Reserve (gal):
    1
  • Fuel Capacity Reserve (l):
    3.8
  • Performance:
    Standard
  • Engine Displacement to Weight (cc):
    2.33
  • Payload Capacity (lbs):
    467
  • Payload Capacity (kgs):
    212
  • Height (in):
    57.7
  • Height (mm):
    1465.6
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Aluminum
  • Body Material:
    Plastic
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    No
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Fork Guards:
    No
  • Hand Guards:
    No
  • Light Guard:
    No
  • Exterior Covers:
    Standard
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Center / Kick
  • Upper Fairing:
    Standard
  • Lower Fairing:
    Standard
  • Spoiler:
    Standard
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Standard
  • License Plate:
    Standard
  • Top Crown:
    Standard
  • Heel Guards:
    Yes
  • Exhaust Guard:
    Yes
  • Tank Guard:
    No
  • Side Cover:
    Yes
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Brand Name:
    Duolever
  • Front Suspension Type:
    Girder
  • Front Travel (in):
    4.9
  • Front Travel (mm):
    125
  • Front Adjustable Fork Pre-Load:
    No
  • Front Central Suspension Strut:
    Yes
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Brand Name:
    Paralever
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    5.3
  • Rear Travel (mm):
    135
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Rear Suspension Material:
    Aluminum
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Front Wheel Width (in):
    3.5
  • Rear Wheel Width (in):
    6
  • Tires:
    Standard
  • Front Tire Width:
    120
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    Z
  • Front Wheel Diameter:
    17
  • Rear Tire Width:
    190
  • Rear Tire Aspect Ratio:
    55
  • Rear Tire Speed Rating:
    Z
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    120/70 ZR17
  • Rear Tire (Full Spec):
    190/55 ZR17
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Optional
  • Chromed:
    No
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Front Brake Diameter (mm):
    320
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    12.6
  • Rear Brake Diameter (mm):
    320
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Standard
  • Speakers:
    Standard
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Satellite:
    Yes
• COMMENTS

  add remove
  • Comment:
    Optional
