Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Engine Stroke:
    4-Stroke
  • Bore (in):
    4.06
  • Stroke (in):
    2.48
  • Displacement (cc):
    1050
  • Horsepower (bhp):
    125
  • Maximum Range (mi):
    217.5
  • Maximum Range (km):
    350
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Primary Drive (Rear Wheel):
    Chain
  • Number Of Speeds:
    6
  • Final Drive Ratio:
    2.47
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    62.2
  • Ground Clearance (in):
    9.8
  • Ground Clearance (mm):
    250
  • Dry Weight (lbs):
    456.4
  • Fuel Capacity (gal):
    6.1
  • Fuel Capacity (l):
    23
  • Engine Displacement to Weight (cc):
    2.3
  • Wet Weight (lbs):
    507.1
  • Wet Weight (kg):
    230
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    8.7
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    8.7
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    WP
  • Rear Suspension Brand Name:
    WP
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    90
  • Front Wheel Diameter:
    21
  • Rear Wheel Diameter:
    18
  • Front Tire (Full Spec):
    Continental TKC 80 Twinduro 90/90 R21 54T
  • Rear Tire (Full Spec):
    Continental TKC 80 Twinduro 150/70 R18 70Q
  • Rear Tire Width:
    150
  • Front Tire Aspect Ratio:
    90
  • Rear Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    T
  • Rear Tire Speed Rating:
    Q
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.5
